ICON 2018-Up Jeep JL Wrangler, 2.5" Lift, Stage 7 Suspension System (K22017)
The ICON Vehicle Dynamics Stage 7 Suspension System is a comprehensive suspension upgrade engineered for 2018 and newer Jeep Wrangler JL models. Designed to dramatically improve ride quality, suspension articulation, and overall off-road capability, this system features dual-rate coil springs, 2.5 Aluminum Series remote reservoir shocks, heavy-duty tubular link arms, and adjustable track bars. With over 30% increased wheel travel compared to stock, this system delivers exceptional control and performance across rugged terrain while maintaining excellent on-road comfort.
2.5” Lift Height for Improved Ground Clearance
This system provides approximately 2.5” of lift front and rear, improving ground clearance and enabling the installation of larger wheel and tire combinations. The increased ride height enhances off-road capability while maintaining predictable handling characteristics on-road.
2.5 Aluminum Series Remote Reservoir Shocks
ICON 2.5 Aluminum Series shocks with remote reservoirs increase oil capacity and cooling efficiency, helping maintain consistent damping performance under demanding driving conditions. These shocks are precision-valved for the Jeep JL platform, improving both ride comfort and off-road control.
Dual-Rate Coil Springs for Comfort and Performance
Dual-rate coil springs improve ride quality during daily driving while delivering increased bottom-out resistance and traction during aggressive off-road use. The progressive design enhances suspension response and stability across varied terrain.
Heavy-Duty Tubular Link Arms for Improved Geometry
This Stage 7 system includes a combination of fixed and adjustable tubular link arms designed to improve caster alignment and maximize articulation. These components enhance suspension strength and reduce bind during suspension movement.
Adjustable Front and Rear Track Bars for Proper Alignment
Adjustable track bars allow precise axle centering after lift installation, ensuring proper suspension geometry and improved steering precision. This adjustment capability enhances overall stability and performance on both highway and trail conditions.
Over 30% Increase in Suspension Travel
ICON engineered this system to significantly increase wheel travel—approximately 3” in the front and 2” in the rear—resulting in improved articulation and traction on uneven terrain. This increased travel enhances both off-road capability and ride comfort.
Supports Larger Tire Fitment for Off-Road Builds
The Stage 7 system supports fitment of up to 35” tires with recommended wheel specifications. Optional bump stop spacers allow installation of 37” tires for more aggressive off-road setups.
Complete Bolt-On System for Straightforward Installation
Designed as a complete bolt-on suspension solution, this system includes all necessary hardware for installation. No cutting or welding is required, making it suitable for professional or experienced DIY installation.
Specifications
- Vehicle Fitment: 2018–Up Jeep Wrangler JL
- SKU: K22017
- Lift Height: 2.5" Front and Rear Lift
- Front Springs: Dual-Rate Coil Springs
- Rear Springs: Dual-Rate Coil Springs
- Front Shocks: ICON 2.5 Aluminum Series Remote Reservoir
- Rear Shocks: ICON 2.5 Aluminum Series Remote Reservoir
- Control Arms: Tubular Steel Fixed and Adjustable Link Arms
- Track Bars: Adjustable Front and Rear Track Bars
- Bump Stops: Bump Stop Spacers Included
- Sway Bar Components: Sway Bar Links Included
- Suspension Travel: Over 30% Increase Compared to Stock
- Wheel Travel Increase: ~3" Front / ~2" Rear
- Recommended Tire Size: Up to 35" (37" with Optional Bump Stop Spacer Kit)
- Wheel Fitment: Compatible with OEM and Aftermarket Wheels
- Shock Construction: Impact-Extruded Aluminum Bodies with Remote Reservoirs
- Material: High-Strength Steel and Aluminum Components
- Serviceability: Fully Rebuildable and Serviceable Shocks
- Install Type: 100% Bolt-On System
- Fitment Notes: Fits 2-Door and 4-Door JL Models
- Use Case: Rock Crawling, Trail Driving, Daily Driving, Off-Road Performance
